DJC-1垊�strong>单根电线电缆燃烧试验�?/strong>中英文简今�/strong>

二、功能特炸�/strong>

Two� product features

DJC-1单根电线电缆垂直燃烧试验机是采用规定尺寸的本生灯 (Bunsen burner) 和特定燃气源 ( 丙烷 ) ，按一定的火焰高度和一定的施焰角度对呈垂直状态的试品定时施燃，以试品点燃、燃烧的持续时间和燃烧长度等来评定其可燃性及着火危险性、�/p>

The vertical burning test of DJC-1 single wire and cable is set by size Bunsen (Bunsen burner) and the specific gas source (Bing Wan)� according to a certain flame height and some application of flame angle on the vertical state of the sample application to test ignition timing� ignition� combustion duration and combustion length evaluation the flammability and fire hazard.

三、主要技术参�?/strong>

Three� the main technical parameters

1.燃烧器：内径��12mm �� 0.5mm（符合GB/T18380.11）及内径��9.5mm �� 0.5mm（符合GB/T18380.21）本生灯各一�?/p>

1 burner: the inner diameter is Phi 12mm + 0.5mm (GB/T18380.11) and the inner diameter is 9.5mm + 0.5mm (GB/T18380.21) by a Bunsen burner

2.试验倾角� 45��

2 test angle: 45

3.火焰高度�?0mm �� 2mm �?90mm��1mm可调

3 flame height: 20mm + 2mm to 190mm + 1mm adjustable

4.施焰时间: 0-999.9s��0.1s可调

4 Shi Yan time: 0-999.9s + 0.1s adjustable

5.持焰时间: 0-999.9s��0.1s，自动记录，手动暂停

5 flame holding time: 0-999.9s + 0.1s� automatic recording� manual pause

6.燃烧气体: 95% 丙烷�? 一般情况可采用液化石油气代� )

6 combustion gas: 95% propane gas (usually liquefied petroleum gas can be used instead)

7.流量压力：带双流量表及压力表（燃气及空气（�/p>

7 flow pressure: with dual flow meter and pressure gauge (gas and air)

8.温度测试范围�?~1000ℂ�/p>

8 temperature measurement range: 0~1000

9.火焰温度要求：从100�?#177;5℃升�?00�?#177;3℃的时间�?5�?#177;5秒之冄�/p>

9 flame temperature requirements: from 100 to 5 degrees Celsius to 700 degrees Celsius 3 degrees Celsius in 45 seconds within 5 seconds

10.火焰应连续燃烧试样，火焰燃烧时间T设定范围0.1-999.9（秒）连续设定；

10 flame should be continuous combustion samples� flame burning time T set range 0.1-999.9 (seconds) continuous set;

11.测温热电偶：��0.5mm进口铠装热电偶（K型）

11 thermocouple: 0.5mm diameter imported armored thermocouple (type K)

12.试验过程：试验程序自动控制，无独立抽飍�/p>

12 test: test program automatic control� without independent exhaust

13.燃气：采用高纯度丙烷气或石油液化气（用户自备）；

13 gas: the use of high purity propane gas or liquefied petroleum gas (user owned);

14.被试验电线电缆长度：600��25mm：�/p>

14 tested wire and cable length: 600 + 25mm;

15.被试验电线电缆外径：导体直径大于0.8mm或截面积大于0.5mm2

15 the diameter of the test wire and cable: conductor diameter greater than 0.8mm or cross-sectional area greater than 0.5mm2

16.本装置应安放在不通风且温度为�?3��10）℃的环境中进行诔�/p>

16 the device should be placed in the environment without wind and temperature (23 + 10).

17.转换开关可根据实际需要选用手动或自动；

17 switch can be selected according to the actual needs of manual or automatic;

18.燃气流量范围�?.1-1L/min：�/p>

18 gas flow range: 0.1-1L/min;

19.空气流量范围�?.1-1m3/h

19 air flow range: 0.1-1m3/h

20.燃烧喷灯标准功率�?KW;

20 standard combustion burner power: 1KW;

21.电源电压�?20V/50Hz

21 power supply voltage: 220V/50Hz

22.箱体材料：钢板静电喷�?或不锈钢机箱 外表无焊点工艹�/p>

22 case material: steel plate electrostatic spray / or stainless steel case appearance without solder joint process

23.工作室尺寸：300x450x1200mm�?.16立方（�/p>

23 studio size: 300x450x1200mm (0.16 cubic meters)

一、使用范図�/strong>

First� the scope of use

DJC-1单根电线电缆垂直燃烧试验仪主要针对导体直径大�?mm(截面积大�?.5mm2)或小�?mm(截面积小�?.5mm2)的单根电线电缆的可燃性能 进行评定。适用于照明设备、低压电器、家用电器、机床电器、电机、电动工具、电子仪器、电工仪表、电气连接件和辅件等电工电子产品及其组件部件的研究、生 产和质检部门、�/p>

DJC-1 vertical burning tester for single wire and cable conductor diameter greater than 8mm (cross-sectional area greater than 0.5mm2 or less than 8mm) (cross-sectional area less than 0.5mm2) Combustible Properties of single cable were evaluated. Suitable for lighting equipment� low-voltage electrical appliances� household appliances� electrical tools� electric motor� electric tools� electronic instruments� electrical instruments� electrical connectors and accessories such as electrical and electronic products and components of the research� production and quality inspection department.

四、随货清協�/strong>

Four� with the cargo list

1 说明� � 1

1 manual copy 1

2 燃烧� � 1

2 combustion chamber 1

3 接物� � 1

3 receiving disc 1

4 保修� � 1

4 warranty card copy 1

5 合格� � 1

5 qualified certificate 1

6 不锈钢块� � 1

A 1 gauge stainless steel 6

五、设计标凅�/strong>

Five� design standards

GB/T18380.11-2008、GB/T18380.12-2008、GB /T18380.21-2008、GB/T18380.22-

GB/T18380.11-2008� GB/T18380.12-2008� /T18380.21-2008 GB� GB/T18380.22-

2008、GB/T5169.14-2007

2008� GB/T5169.14-2007

六、适用标准

Six� applicable standards

IEC60332 � GB/T19666-2005� GB12972 � GB13033 � MT818、MT386、ISO5656

IEC60332� GB/T19666-2005� GB12972� GB13033� MT818� MT386� ISO5656
