产品简今/div>
特点及优劾/span>
与传统的铁氧体软磁材料相比，纳米晶软磁合金材料具有高饱和磁感（≥1.2T），低损耗，低矫顽力，低磁致伸缩，磁导率可调范围宽（400-900,000），良好的温度稳定性，是高频电力电子应用理想的选择、/span>
典型应用
高精度纳米晶带材主要用于制作高端共模电感、高频功率变压器、精密电流互感器，磁放大器和屏蔽片等产品、/span>
参数说明
| 产品牌号 | 有效厚度 | 堆积 系数 |
饱和通量密度 | 矫顽劚/strong> | 案例 | ||||||||||||
| 高频电力变压器（HFPT（/strong> | 共模扼流 (CMC) | 电流互感?CT) | 无线电力传输(WPT) | ||||||||||||||
| t [μm] | % | Bs[T] | Hc[A/m] | Select | Pcm [W/kg] (20kHz,0.5T) |
μ0.08 | Select | Pcm [W/kg] (100kHz,0.3T) |
μ (10kHz) |
μ (100kHz) |
Select | μi (50Hz) | μm (50Hz) | Select | Pcm [W/kg] (100kHz,0.3T) |
μ (100kHz) |
|
| 1K107B | 23-26 | 78-84 | 1.24 | ?.5 | ∙/td> | ?0 | 30,000~60,000 | \ | \ | \ | \ | ∙/td> | 85,000 | 500,000 | \ | \ | \ |
| 20-23 | 78-84 | ∙/td> | ?5 | 30,000~60,000 | ∙/td> | ?0 | 80,000 | 15,000 | ∙/td> | 80,000 | 500,000 | \ | \ | \ | |||
| 17-20 | 75-82 | ∙/td> | ?2 | 30,000~60,000 | ∙/td> | ?0 | 75,000 | 25,000 | \ | \ | \ | \ | \ | \ | |||
| 14-17 | 75-82 | \ | \ | \ | ∙/td> | ?0 | 70,000 | 30,000 | \ | \ | \ | \ | \ | \ | |||
| 1K107BW | 22-28 | 78-84 | 1.24 | ?.5 | ∙/td> | ?5 | \ | ∙/td> | ?5 | 80,000 | 15,000 | ∙/td> | 140,000 | 500,000 | \ | \ | \ |
| 1K107E | 18-22 | 78-84 | 1.24 | ?.5 | \ | \ | \ | \ | \ | \ | \ | ∙/td> | 150,000 | 500,000 | \ | \ | \ |
| 1K107O | 22-28 | 78-84 | 1.24 | ?.5 | \ | \ | \ | \ | \ | \ | \ | ∙/td> | 140,000 | 900,000 | \ | \ | \ |
| 1K107W | 14-26 | 75-84 | 1.24 | ?.5 | \ | \ | \ | \ | \ | \ | \ | ∙/td> | \ | \ | ∙/td> | ?0 | ?2,000 |
| 1K107H | 18-26 | 78-84 | 1.40 | ?.5 | \ | \ | \ | \ | \ | \ | \ | \ | \ | \ | ∙/td> | ?10 | ?4,000 |
| FN-200 | 20-23 17-20 |
78-84 | 1.25 | ?.0 | \ | \ | \ | ∙/td> | ?0 | 20,000 | 12,000 | \ | \ | \ | \ | \ | \ |
| FN-100 | 78-84 | ?.5 | \ | \ | \ | ∙/td> | ?0 | 8,500 | 7,500 | \ | \ | \ | \ | \ | \ | ||
| FN-080 | 78-84 | ?.5 | \ | \ | \ | ∙/td> | ?0 | 5,500 | 5,000 | \ | \ | \ | \ | \ | \ | ||
| FN-035 | 78-84 | ?.0 | \ | \ | \ | ∙/td> | ?0 | 4,500 | 4,500 | \ | \ | ||||||
