ZLG系列振动流化床干燥冷却机_报价-四川川大干燥科技工程有限责任公司.

制粒干燥设备

产品简今�/div>

简介：

工作原理 WORKING PRINCIPLE９�/font>

物料自进料口进入机内，在振动力作用下物料沿水平流化床抛掷，向前连续运动，热风向上穿过流化床同湿物料换热后，湿空气旋风分离器除尘后由排风口排出，干燥物料由排料口排出、�/div>

Raw material is fed into the machine from the inlet and moves forward continuously along with the level of fluidized and carries out hot geat exchange with damp raw material. Then the damp air is exhausted out through cyclone separator and duster and the dry raw material is discharged through discharge outlet.

适用范围 SCOPE OF APPLICATION９�/font>

医药化工：各种压片颗粒、硼酸、硼砂、苯二酚、苹果酸、马来酸等、�/li>
食品建材：酒槽、味精、砂糖、食盐、豆瓣、种籽、矿渣等、�/li>
还可以用于物料冷却、增湿等、�/li>
该机适用于料度分布较广的松散性粉状和料状的干燥、�/li>
Pharmaceutical and chemical industries:all kinds of press tablet and granule, boric acid, borax, dihydroxybenzene, malic acid, maleic acid and so on;
Foodstuff and construction material industries:less, monosodium, edible sugar, edible salt, mine residue, bean, seeds and so on.
It can also used for raw materials to add up damp or cooling and so on.
This model is used for the drying of incompact powder and granules.

产品特点 PRODUCT FEATURES９�/font>

物料受热均匀，热交换充分，干燥强度高，比普遍干燥机节�?0%左右、�/li>
振动源是采用振动电机驱动动，运转平衡、维修方便、噪音低、寿命长、�/li>
流动化稳、无死角和吹穿现象、�/li>
可调性好，适应面宽，料层厚度在机内移动速度以及振幅变更均可实现无级调节、�/li>
对物料表面损伤性小，可用于易碎物料的干燥，物颗粒不规则晨亦不影响工作效果、�/li>
采用全封闭式的结构，有效的防止了物料与空气间的交污染，作业环境清洁、�/li>
Raw material is heated evenly and heat exchange is fully used and dry capacity is high. Compared with ordinary drier, the energy can be saved about 30%.
The vibration is crated by motor. It is stable in operation and convenient in maintenance, low noise and long life.
The fluidized state is stable and no dead angle and phenomenon of broken out.
It is good in regulation and wide in suitability, the thickness of raw material layer and movable speed inside the machine and the amplitude can be adjusted through continuous bariable speed.
It is small for damaging the surface of raw material. The equipment can be used for drying raw materials that are easy broken. The drying effect can not be affected even if raw materials have anomaly shape.
It is effective to prevent from cross pollution between raw material and air because the equipment adapts fully closed structure. The enbvironment of operation clean.
