特点 FEATURE

任何颗粒、粉末、粘液一定范围内均可筛选。筛�?细至500目或0.002mm，过�?小可�?微米。分级筛选，可筛一至五层筛网，能同时进行二至六个等级的分选或过滤。效率高、设计精巧耐用，换网容易、操作简单、清洗方便。旋振筛杂质、粗料自动排出，可以连续作业。独特网架设计，筛网使用时间长久，换网快，只需3-5分钟。体积小，节省空间，移动方便、�/span>

Any particle, powder or mucus can be screened within a certain range. The sieve is as fine as 500 mesh or 0.002 mm, and the filtration can be as small as 2 micrometers. The grading screening can screen one to five layers of screens, and can perform two to six levels of sorting or filtering at the same time. High efficiency, exquisite design and durability, easy to change screen, easy to operate and easy to clean. The vibrating screen impurities and coarse materials are automatically discharged, which can be continuously operated. Unique grid design, the screen is used for a long time, and the screen is fast, only 3-5 minutes. Small size, space saving and easy to move.

应用领域APPLICATION FIELD

◆化工行业：树脂、涂料、工业药品、化妆品、油漆、中药粉等、�/span>

◆食品行业：糖粉、淀粉、食盐、米粉、奶粉、豆浆、蛋粉、酱油、果汁等、�/span>

◆金属、冶金矿业：铝粉、铅粉、铜粉、矿石、合金粉、焊焊条粉末、二氧化锰、电觖铜粉、电磁性材料、研磨粉、耐火材料、高岭土、石灰、氧化铝、重质炭本酸钙、石英砂等、�/span>

◆其它行业：废油、废水、染整废水、造纸、助剂、活性炭等、�/span>

◆Chemical industry: resins, coatings, industrial pharmaceuticals, cosmetics, paints, Chinese medicine powder, etc.

◆Food industry: powdered sugar, starch, salt, rice flour, milk powder, soy milk, egg powder, soy sauce, juice, etc.

◆Metal, metallurgical mining: aluminum powder, lead powder, copper powder, ore, alloy powder, welding electrode powder, manganese dioxide, electric copper powder, electromagnetic material, abrasive powder, refractory material, kaolin, lime, alumina, heavy Calcium carbonate, quartz sand, etc.

◆Other industries: waste oil, wastewater, dyeing and finishing wastewater, paper making, additives, activated carbon, etc.

工作原理WORKING PRINCIPLE

振动筛由立振动电机作激振源，振动电机上、下两端安装有偏心重锤，将振动电机的旋转运动转变为不平、垂直、倾斜的三次元运动，再把这个运动传递给筛面。调节上、下两端的相位角，可以改变物料在筛面上的运动轨迹、�/span>

The vibrating screen is used as the excitation source by the vertical vibration motor. The upper and lower ends of the vibrating motor are equipped with eccentric weights, which transforms the rotary motion of the vibrating motor into an uneven, vertical and inclined three-dimensional motion, and then transmits this motion to the screen surface. . Adjusting the phase angle of the upper and lower ends can change the trajectory of the material on the screen surface.

结构原理国�/strong>STRUCTURAL SCHEMATIC DIAGRAM

分级：将物料精确分为2-6个等�?/span>

过滤：去除液体中的颗粑�/span>

除杂：去除不合格的物斘�/span>

Classifying: Precisely classifying the materials into 2-6 grades

Filtering: Removing particles in the liquid

Impurity removing: Removing nonconforming materials
