Parameters |
Typical values |
|
波长公差 Wavelength tolerance |
±3nm |
|
工作模式 Working mode |
CW |
|
功率稳定?/span>(%) (8 hours, ±3°C) Long-Term Power Stability (%) (8 hours,±3°C) |
±1% |
|
噪声@20 Hz to 20kHz Noise |
RMS |
≣/span>0.1% |
Pk to Pk |
≣/span>1% |
|
供电电压 Power Supply Voltage |
5V&9V&12V |
|
热沉功率 Power Dissipation |
<10W |
|
寿命 Lifeime |
10000hours |
|
底板温度 Laser Head Baseplate Temperature |
10 to 40ℂspan style="box-sizing: border-box; margin: 0px; padding: 0px; border: 0px; font-family: 方正黑体简佒">＇/span>Working（/span>; -20 to 60ℂspan style="box-sizing: border-box; margin: 0px; padding: 0px; border: 0px; font-family: 方正黑体简佒">＇/span>Non-working（/span> |
|
湿度 Humidity |
15% - 90% |
|
预热时间 Warm-up Time |
<3mins |
|
尺寸（可定制（/span> Size(Customizable) |
106X48X35mm |
|
激光辐射等?/span> Laser radiation level |
Class 3B |
|
波长＇/span>nm（/span> Wavelength |
**输出功率(mW) Max power output |
工作距离(m) Working distance (mm) |
线宽(µm) Line width |
扇形光束角度＇/span>°（/span> Fan-beam Angle( Optional) |
375nm |
55 |
1-1000 |
30-500 |
5° 10° 15° 30° 45° 60° 75° 90° |
405nm |
220 |
|||
450nm |
55 |
|||
488nm |
150 |
|||
505nm |
35 |
|||
515nm |
65 |
|||
525nm |
65 |
|||
640nm |
150 |
|||
650nm |
10 |
|||
660nm |
100 |
|||
670nm |
10 |
|||
685nm |
40 |
|||
785nm |
80 |
|||
808nm |
70 |
|||
830nm |
40 |
|||
980nm |
150 |
|||
1064nm |
100 |
机械尺寸及安装（可定制）
Mechanical dimensions and installation (Customizable)
